Label printer Alpha, 200dpi
4" Thermal Transfer Label Printer
-
The modular design of print head makes the disassembly and assembly easy
-
With the function to automatically identify the printer head with 203 dpi and 300 dpi and automatically configure the printer without PC settings
-
With super large storage, DDR2 RAM 128 MB, Flash 256 MB
-
With free label editing software Bartender to mark the label editing convenient and easy
-
With various media to meet the demand of wide area
-
Cool black housing with clamshell structure, with external paper roll holder optional supported.
- Brand: DATECS
- Weight: 1.800 Kgs
Printing | Printing Method | Thermal transfer | |
Resolution | 203 dpi / 300 dpi | ||
Max.Printing Speed |
8 ips (203dpi) / 6 ips (300dpi) | ||
Max.Printing Width |
108 mm(203dpi) / 106 mm(300dpi) | ||
Max.Pringting Length |
2,286 mm(203dpi) / 1,524 mm(300dpi) | ||
Protocol | Compatible ZPL-II, EPL2, DPL | ||
Interfaces | Standard | USB Type B, Serial, Ethernet | |
Optional | Bluetooth, Wi-Fi | ||
Memory | RAM | 128 MB | |
Flash | 256 MB | ||
Media | Width | 25.4mm~118 mm | |
Thickness | 60μm~250μm | ||
Roll(OD., Max) |
127 mm | ||
Ribbon | Type | Wax,Wax/Resin,Resin | |
Width | 30 mm~110 mm | ||
Max.Length | 100 m | ||
Inradium | 25.4 mm | ||
Font | Resident Fonts | Alphanumeric, Simplified Chinese, Traditional Chinese, 29 International Character Sets | |
Download Fonts | Support | ||
Software |
Label Design Software |
Bartender 2016 Ultralite | |
Driver | HPRT Driver:Windows XP,Vista,7,8,10.Linux,Mac | ||
Barcodes | Linear | UPC-A,UPC-E,EAN 128,Codabar,Code 128Code 39, Code 93, EAN-8,EAN-13,UCC/EAN-128, Post NET, ITF 14, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13, Japanese Postnet, Interleaved 2 of 5, Standard 2 of 5, Industrial 2 of 5, Logmars, Code 11 | |
2D | Code 49, Cadablock, PDF417, Data matrix code, Maxi Code, QR code, Micro PDF471, Aztec | ||
Sensor | Gap Sensor | Transmissive (Fixed, Dual) | |
Black mark Sensor | Reflective (Adjustable, Full-Range) | ||
Other | Paper out detect, Ribbon out detect, Print head left detect, print head temperature detect | ||
Electrical | Input | AC 100~240V, 50/60 Hz | |
Output | DC 24V, 2A | ||
Environmental | Operation | 5 to 50℃@ humidity 25% to 85% non-condensing | |
Storage | -40 to 60℃@ humidity 10% to 90% non-condensing | ||
Physical Characteristic |
Dimension (L×H×W) |
252×201×181 mm | |
Weight | 1.95 kg | ||
Options & Accessory | Black E4P External label Peeler Module, Black E4GC External Cutter Module, External Label Roll Holder | ||
Agency Approval | CE EMC(EN 55022 Class B), FCC EMC(Class A), CCC, RoHS |
Drivers and Manuals
Stay up-to-date with the latest downloads for your HPRT Printer
Функционални и Технически Параметри
Захранване | Aдаптер AC/DC, AC 100-240V,50/60Hz, DC 24V 2A |
Принтер | Термотранферен/Термодиректен |
Консуматив | Термохартия, ширина от 30 мм до 118 мм, макс. дебелина 0.25мм, макс. диаметър на ролката 127 мм. |
Скорост на печат | 150 мм/с при 300 dpi и 200 мм/с при 203 dpi |
Резолюция на печат | 203 dpi / 300 dpi |
Термотрансферна лента | Wax,Wax/Resin,Resin |
Ширина на термотрансферна лента | 30 мм до 110 мм |
Дължина на термотрансферна лента | 100 м. |
Интерфейси |
– USB Type B стандартно
– Wi-Fi/BT опционално
|
Сензори | GAP сензор, Черен маркер, Край на ролката, Край на лентата, Отворен капак, Прегряване на печ.глава |
Индикации | 2бр. Led |
Съвместимост с OS | Windows 7/8/8.1/10 Linux,Mac OS |
Етикетна ролка |
– Непрекъсната хартия
– Отлепващи се етикети
– Етикети с черен маркер
– Етикети с перфорация
|
Бутони | 2 бр. |
Тегло | 1.8 кг. |
Размер | 181 х 252 х 201 мм. |
- Printing Mechanism:
- Printing Width:
- Printing Resolution:
- Printing Speed:
- Printable Font Sizes:
- Printable Barcode Types: EAN8, EAN13, UPC-A/E, ITF, Code 39, Code 93, Code 128, Codabar, PDF 417
- Paper Type: Label rolls
- Paper Width:
- Paper Thickness:
- Roll Max Diameter:
- Emulation:
- Connectivity:
- LED Indication:
- Reliability:
- Dimensions: (W x D x H), 106 x 184 x 110 mm
- Weight:
- Operational temperature range: -10 to 40 °C, 35 to 85 % RH
- Storage temperature range: -20 to 60 °C, 10 to 90 % RH
Brand: |
DATECS |
---|---|
Print Method: |
Thermal transfer / Direct thermal |
Resolution: |
203 dpi (8 dots/mm) |
Printing material type (Roll Typel) : |
Thermal transfer label rolls Direct thermal label rolls Foil (PP, PE, PET, PVC) label rolls |
Manufacturer/Country of origin: |
Datecs, Bulgaria |
Warranty: |
1 year |
File | Info |
---|---|
АЛФА-Ръководство за потребителя-easylabelbg.com | [PDF, 3.31 MB] |
